Resolution
|
256X192 |
384X288
|
640X512
|
|
NETD
|
≤50mK@25℃,F#1.0
|
≤30mK@25℃,F#1.0
|
≤25mK@25℃,F#1.0
|
|
Pixel pitch
|
12μm
|
||
|
Working band
|
8~14μm
|
||
|
Frame rate
|
50Hz
|
||
|
Range measurement
|
10m-1200m
|
||
|
Range accuracy
|
<400m±1m,>400m±0.4%
|
||
|
Focal length
|
25mm
|
35mm | 35mm |
|
Magnification
|
5.7x
|
3.4x
|
2.2x
|
|
FOV
|
7.0°×5.4°
|
7.5°×5.7°
|
12.5°×10.0°
|
|
Focus mode
|
Manual focus
|
||
|
Lens aperture
|
1.0
|
||
|
Focus range
|
5m-∞
|
||
|
Detection distance
|
708m/1180m
|
1180m/1653m
|
1653m
|
|
Vehicles
|
1875m/3125m
|
3125m/4375m
|
4375m
|
|
Identification distance
|
|
||
|
Human
|
177m/295m
|
295m/413m
|
413m
|
|
Vehicles
|
468m/781m
|
781m/1094m
|
1094m
|
|
Eye relief
|
18.5mm
|
||
|
Diopter adjustment
|
±4D
|
||
|
Photo & Video recording/
CVBS/
Hot Tracking/
WIFI/
|
Supported
|
Supported
|
Supported
|
|
Display type
|
OLED
|
|
|
|
Resolution & Display size
|
800x600 (0.32 inches)
|
|
|
|
Language
|
The supported language can be set in the language setting
|
|
|
|
E-zoom
|
1X/2X/4X
|
1X/2X/4X/8X
|
1X/2X/4X/8X
|
|
Pseudo colors
|
white hot, black hot, red hot,rainbow, iron red and cool color
|
|
|
|
External power supply
|
5V (USB-C)
|
|
|
|
Capacity
|
Built in 16GB EMMC (The system takes up some space, actually about 13.8G)
|
|
|
|
Rechargeable lithium battery
|
18650 (3200mAh
|
|
|
|
Operating time
|
≥7h
|
≥6h
|
≥4h
|
|
Spatial resolution
|
0.8mrad/
0.48mrad
|
0.48mrad/
0.34mrad
|
0.34mrad
|
|
Protection level
|
IP66
|
|
|
