Description
A real test by youtube blogger: https://www.youtube.com/watch?v=wtWWrbw7SUQ
Enter the password: 2048
HT-C19L comes with a rifle mount.
HT-C19L MANUAL:Download
How to open the crosshairs function:Download
We are looking for distributors, please contact us: hti08@outlook.com






| Thermal resolution |
640×512 |
|
Detector type |
Vanadium oxide uncooled infrared focal plane |
|
Pixel size |
12μm |
|
Focus length/ Field angle |
25mm/35mm/54mm 17.5°×14.0°/12.5°×10.0° |
|
Ranging range
(building)
|
10m~1500m
|
|
Distance measurement
accuracy (building)
|
<400m ±1m ,>400m ±0.4%
|
| Work band |
8~14μm |
|
NETD |
≤ 40mk@25℃,@F/1.0 |
|
Frame rate |
≤50Hz |
|
Focusing mode |
Manual |
|
Detection range |
|
|
Character 1.7mx0.5mx0.3m |
25mm 35mm 2361m 3306m |
|
Vehicle 4.5mx2.0mx1.5m |
25mm 35mm 6250m 8750m |
|
Perception distance |
|
|
Character 1.7mx0.5mx0.3m |
25mm 35mm 590m 826m |
|
Vehicle 4.5mx2.0mx1.5m |
25mm 35mm 1563m 2188m |
|
Display screen type |
OLED |
|
Resolution ratio |
1440×1080 |
|
Display size |
0.39inches |
|
Electronic zoom |
1×/2×/4×/8× |
|
Diopter regulation |
±5SD |
|
Palette |
White hot, Black hot, Fire hot,Rainbow, Iron red, Cold color |
|
Hot point track |
Supported |
|
Picture in picture |
Supported |
|
Language |
Chinese, traditional Chinese, English,Russian, German |
|
Capacity |
Built-in 16G EMMC(The system takes up some space and it is 13.8G actually) |
|
Photographing |
Supported |
|
recording |
Supported |
|
Image/video format |
JPG/MP4 |
|
USB interface |
Charging/export image and video |
|
Detachable rechargeable lithium battery |
1400mAh×2(battery model 18350) |
|
Overall power consumption |
≤1.8W |
|
Time of endurance |
≥5 hours |
|
Work temperature |
-20℃ ~ +60℃ |
|
Storage temperature |
-30℃ ~ +70℃ |
|
Impact |
≤1000G |
|
Protection grade |
IP66 |
|
Product size |
196.5x96x66mm |
|
Product weight |
700g |
