HT-203U Mobile Phone Thermal Imager(256×192)


Price:
Sale price$179.00

Description

203H and 203U have different field angles and other functions are the same.

Detector type :

Amorphous silicon uncooled infrared focal plane

Infrared image

resolution:

256x192

 Pixel spacing:

12μm

Focal length:

3.5mm

Angle of view:

 50.0°(H)×37.2°(V)

IFOV:

 3.43mrad

Working band:

 8~14μm

 NETD:

 ≤ 40mk@25℃,@F/1.2

 Image frame rate:

 ≤25Hz

Focusing mode:

 Free Focus

Brightness

adjustment:


Supported

Contrast

adjustment:


Supported

palettes:


White Hot,Black Hot,Blend,Iron,Dark Brown,Red Hot,

Green Hot,Rainbow

Temperature

measurement method:


point, line and regional

temperature measurement

Temperature

measurement range:


-20 ℃ ~ 120 ℃ and 120 ℃ ~ 550 ℃

Temperature

measuring distance:


0.3m~3m

Temperature

measurement resolution:


± 2 ° C or reading ± 2%

Camera/video:

 Supported

Picture /Video format:

 JPG/MP4

Language:

 Chinese, English, Russian

Power consumption:

 ≤0.36W

External interface:

 USB Type-C, DC5V power supply

Working temperature:

 -20℃ ~ +50℃

Storage temperature:

 -30℃ ~ +70℃

Protection level:

 IP54

 Product size:

 46x70x14mm

Product weight:

 28g

App Download link(11/04/2023 Upload):

 Click to download

HT-203U MANUAL:download
