HT-C19 Thermal Imaging rifle scope(640×512)

Save $100.00

Lens: 35mm
Price:
Sale price$1,719.00 Regular price$1,819.00
Stock:
Re-stocking soon

Description

Recording video, including crosshairs information:

Press 10 times in the Picture-in-Picture function.
Enter the password: 2048

HT-C19 have crosshairs and Bracket.

HT-C19 MANUAL:Download

How to open the crosshairs function:Download

We are looking for an agent, please contact us: hti08@outlook.com

Thermal resolution

640×512

Detector type

Vanadium oxide uncooled infrared focal plane

Pixel size

12μm

Focus length/

Field angle

25mm/35mm/54mm/75mm

17.5°×14.0°/12.5°×10.0°/8.1°×6.5°/5.9°×4.7°

Work band

8~14μm

NETD

≤ 40mk@25℃,@F/1.0

Frame rate

 ≤50Hz

 Focusing mode

 Manual

Detection range



Character

1.7mx0.5mx0.3m

25mm     35mm     54mm    75mm

590m      826m      1275m     1771m

Vehicle

4.5mx2.0mx1.5m

25mm      35mm     54mm     75mm

1563m     2188m    3375m     4688m

 Perception distance



Character

1.7mx0.5mx0.3m

25mm     35mm     54mm    75mm

2361m     3306m    5100m   7083m

 Vehicle

4.5mx2.0mx1.5m

25mm     35mm      54mm       75mm

6250m     8750m    13500m    18750m

Display screen type

 OLED

 Resolution ratio

 1440×1080

Display size

 0.39inches

Electronic zoom

 1×/2×/4×/8×

Diopter regulation

±5SD

Palette

 White hot, Black hot, Fire hot,Rainbow, Iron red, Cold color

Hot point track

 Supported

Picture in picture

 Supported

Language

 Chinese, traditional Chinese, English,Russian, German

Capacity

 Built-in 16G EMMC(The system takes up some space and it is 13.8G actually)

Photographing

 Supported

recording

 Supported

Image/video format

 JPG/MP4

USB interface

 Charging/export image and video

Detachable rechargeable lithium battery

 1400mAh×2(battery model 18350)

Overall power consumption

 ≤1.8W

Time of endurance

 ≥5 hours

Work temperature

 -20℃ ~ +60℃

Storage temperature

 -30℃ ~ +70℃

Impact

 ≤1000G

Protection grade

 IP66

Product size

 198x57.5x64.3mm

Product weight

 580g
